Фрезерно-гравировальный станок 4D с ЧПУ E2-2040C (9KW CS) - A Axis

Travelling area: 2080*4000*420mm ES929X HSD 9KW spindle-ISO interface Syntec FC-60WA (+ 4th axis)

    Yaskawa driving system-(XYZ:750W; A:400W)

A axis rotates only when the Z axis is in 0 point during manual model 5.5KW 250 Chinese pump-2sets

8 positions linear tool magazine HSK 63 Tool holder--3 pcs (ER40) lock knife block HSK 63

control vacuum zones via manual valves Auto tool sensor

    Moving Positioning cylinders A axis:±90℃

   T-slot vacuum table, 6 vacuum zones

Oil gun&Total multis complex HV2 oil-400g-1pc

Pump control on cabinet dust cover on spindle

    High precision helical rack &pinion Japanese SHIMPO metal Reducer THK Linear rail

   DELTA inverter

Air plug + heavy duty plug 3PH 380V 50HZ

    Plywood package

1. tools-4 pcs

2. plastic tool clampers-2 sets 3.limit sensors - 2 pcs

4. brush-1 extra set(there is one set on machine already)

5. table rubber strips:30 meters extra

6. collets-4 pcs
